UL1007 PVC Insulated Hook-Up Wire – 300V, 80°C, Stranded or Solid Copper Conductor | HANYI Cable

UL1007 is a PVC insulated hook-up wire designed for internal wiring applications requiring 300V voltage rating and 80°C temperature resistance. With its flame-retardant PVC insulation and tinned copper conductor, it ensures durability, flexibility, and safe performance in a variety of industrial and electronic environments.

Description Package Information Inquiry

Detailed Description

The UL1007 hook-up wire is a high-quality single-core cable designed for internal wiring of electrical and electronic equipment. It features a tinned or bare copper conductor for excellent conductivity and corrosion resistance, insulated with PVC for mechanical protection, flexibility, and reliable electrical performance.

Rated at 300 volts and 80°C operating temperature, UL1007 wire is widely used in control panels, appliances, lighting systems, electronic devices, and internal wiring of industrial equipment. The PVC insulation offers good resistance to oil, moisture, acids, alkalis, and abrasion.

UL1007 complies with UL Standards for safety and performance, making it a trusted choice for both OEM manufacturing and maintenance applications.

Key Features

Rated voltage: 300V
Rated temperature: 80°C
Conductor: Stranded or solid tinned/bare copper (per UL 758, UL 1581)
Insulation: PVC, flame retardant, moisture resistant
Standard compliance: UL1007, RoHS compliant
Colors available: Black, red, blue, yellow, green, white, and custom colors
Applications: Internal wiring of appliances, electronic devices, control panels, lighting fixtures

Technical Specifications

Parameter	Description
Conductor Material	Tinned or bare copper
Conductor Structure	Solid or stranded
Conductor Size	30–16 AWG
Insulation Material	PVC (Polyvinyl Chloride)
Voltage Rating	300V
Temperature Rating	-20°C to +80°C
Flame Test	UL VW-1
Standards	UL 758, UL 1581, RoHS

305m, 610m Coil/Drum upon request
