Product Overview
Chain Flex cable is a highly flexible, PVC-insulated and sheathed control cable designed for industrial machinery, automation systems, and electrical installations. Its construction ensures easy routing, reliable signal transmission, and long-term performance in environments with light mechanical stress.
It is widely used in control panels, distribution boards, machine tools, and low-voltage industrial automation circuits. The cable combines flexibility with mechanical and chemical resistance, making it suitable for fixed or semi-fixed installations.
Key Features
Flexible PVC Insulation & Sheath: Enables smooth routing and easy installation.
Voltage Rating: 300/500V or 450/750V.
Temperature Range: -5°C to +70°C.
Flame-Retardant Option Available: Ensures safety in industrial environments .
Mechanical & Chemical Resistance: Protects against abrasion, tearing, and light chemical exposure.
Multiple Core Configurations: Typically 2–24 cores with conductor sizes 0.5–2.5 mm².
Standards Compliance: Manufactured according to GB/T 5023 domestic standards.
Typical Applications
Control circuits in industrial machinery
Electrical panels and distribution boards
Low-voltage wiring for automation systems
Signal and power transmission in light mechanical environments
Fixed or semi-fixed installations where flexibility is required
Technical Specifications
| Parameter | TRVV Cable |
|---|---|
| Insulation Material | Special PVC |
| Sheath Material | Special PVC or PUR |
| Voltage Rating | 300/500 V or 450/750 V |
| Operating Temperature | -5°C to +70°C |
| Flexibility | Flexible, suitable for fixed/semi-fixed installation |
| Flame Retardant Option | Available (FD) |
| Mechanical Resistance | Good abrasion and chemical resistance |
| Core Count & Size | 2–24 cores, 0.5–2.5 mm² |
100m/200m/ 500m/ 1000m/drum upon order request
