1. H05VV-F Flexible PVC Cable
Product Title:
H05VV-F Harmonized Light-Duty PVC Flexible Cable – 300/500V, CE/VDE Certified | HANYI Cable
Summary:
Light-duty harmonized PVC flexible cable for household appliances, office equipment, and light mechanical stress applications. Certified to CE and VDE standards for safe, reliable performance in Europe, Asia, and global markets.
Detailed Description:
H05VV-F is a harmonized, light-duty flexible cable designed for use in domestic and light industrial environments under low mechanical stress. It consists of fine-stranded copper conductors (Class 5, IEC 60228) with PVC insulation and an overall PVC sheath. The cable is suitable for connecting small appliances, office devices, kitchen equipment, and portable tools in dry or damp indoor conditions.
Common applications include refrigerators, washing machines, desktop computers, and printers.
The product meets VDE 0281, HD 21.5 S3, IEC 60227-5, and CE directives, ensuring compliance with European market requirements.
Technical Specifications:
| Parameter | Value |
|---|---|
| Voltage Rating | 300/500 V |
| Conductor | Fine-stranded bare copper, Class 5 |
| Insulation | PVC, color-coded cores |
| Sheath | PVC, available in black, white, or gray |
| Core Count | 2–5 cores |
| Cross Section | 0.75–2.5 mm² |
| Temperature Range | –5°C to +70°C (flexing) / –40°C to +70°C (fixed) |
| Minimum Bend Radius | 7.5× outer diameter (flexing) |
| Standards | VDE 0281, IEC 60227-5, CE, RoHS compliant |
| Flame Rating | IEC 60332-1 |
2. H07VV-F Flexible PVC Cable
Product Title:
H07VV-F Harmonized Heavy-Duty PVC Flexible Cable – 450/750V, CE/VDE Certified | HANYI Cable
Summary:
Heavy-duty harmonized PVC flexible cable for industrial equipment, construction sites, and outdoor-rated appliances under medium mechanical stress. Certified to CE and VDE for global use.
Detailed Description:
H07VV-F is a harmonized, heavy-duty flexible cable suitable for power supply to equipment and appliances operating under medium mechanical stress. It is commonly used in industrial plants, workshops, construction sites, and outdoor environments. The cable features fine-stranded copper conductors (Class 5, IEC 60228) with PVC insulation and an overall PVC sheath, offering high durability and resistance to abrasion and oils.
Typical uses include mobile power distribution boards, heavy-duty tools, industrial vacuum cleaners, and portable heating devices.
The cable complies with VDE 0281, HD 22.4 S3, IEC 60227-6, and CE requirements, making it suitable for export to Europe, the Middle East, Africa, and the Americas.
Technical Specifications:
| Parameter | Value |
|---|---|
| Voltage Rating | 450/750 V |
| Conductor | Fine-stranded bare copper, Class 5 |
| Insulation | PVC, color-coded cores |
| Sheath | PVC, heavy-duty grade |
| Core Count | 2–5 cores |
| Cross Section | 1.0–16 mm² |
| Temperature Range | –5°C to +70°C (flexing) / –40°C to +70°C (fixed) |
| Minimum Bend Radius | 6× outer diameter (flexing) |
| Standards | VDE 0281, IEC 60227-6, CE, RoHS compliant |
| Flame Rating | IEC 60332-1 |
5000m, 1000m, 100m upon request
