LSZH Flexible Low Smoke Zero Halogen Mineral Insulated Thermocouple Extension Cable | HANYI Cable
Halogen-free, flame-retardant flexible LSZH cable
Description
Package Information
Inquiry
Halogen-free, flame-retardant flexible cable widely used in high-safety environments (data centers, subways, hospitals). Compliant with GB/T 19666-2005 (China) and IEC 60754/61034 (international), it features:
Low smoke & toxicity (pH ≥4.3, light transmittance ≥60%).
Flame retardant (Class B/C per GB/T 18380).
Flexible design (Class 5 stranded copper).
Technical Specifications
| Parameter | Details |
|---|---|
| Standard | GB/T 19666-2005, IEC 60754, IEC 61034 |
| Conductor | Bare copper (Class 5, finely stranded) |
| Insulation | XLPE (Cross-linked Polyethylene) |
| Sheath | LSZH (Low Smoke Zero Halogen) |
| Voltage | 300/500V |
| Temperature | -20°C to +70°C (operating), +105°C (short circuit) |
| Flame Retardancy | Passes IEC 60332-1 (vertical flame test) |
| Core Colors | Black with white numbering or custom (e.g., brown/blue/yellow-green) |
5000m, 1000m, 100m upon request
