LiYCY Flexible PVC Control and Signal Cable – Screened, Multi-Core, Shielded | HANYI Cable
Which Cable to Choose – LiYY, LiYCY or LiYCY (TP)
Comparison Table – LiYY vs LiYCY vs LiYCY (TP)
| Feature / Model | LiYY | LiYCY | LiYCY (TP) |
|---|---|---|---|
| Core Structure | Multi-core, straight lay | Multi-core, straight lay | Multi-core, twisted pairs |
| Shielding | None | Tinned copper braid, optical coverage ≥ 85% | Tinned copper braid, optical coverage ≥ 85% |
| EMC Protection | No | Yes | Yes – plus reduced crosstalk |
| Interference Resistance | Low | High (against external EMI) | Very high (against EMI and internal crosstalk) |
| Typical Conductor Sizes | 0.14 mm² – 1.0 mm² | 0.14 mm² – 1.0 mm² | 0.14 mm² – 1.0 mm² |
| Core Identification | DIN 47100 | DIN 47100 | DIN 47100 |
| Outer Sheath | PVC, grey (RAL 7001) | PVC, grey (RAL 7001) | PVC, grey (RAL 7001) |
| Voltage Rating | 300/500 V | 300/500 V | 300/500 V |
| Temperature Range (Fixed) | −40 °C to +80 °C | −40 °C to +80 °C | −40 °C to +80 °C |
| Temperature Range (Flexing) | −5 °C to +70 °C | −5 °C to +70 °C | −5 °C to +70 °C |
| Applications | General control & signal | Control & signal with EMI protection | Data/control with EMI + crosstalk reduction |
| Main Advantages | Economical, easy to install | Strong EMI shielding | Strong EMI shielding + improved signal integrity |
Detailed Description
The LiYCY cable is a high-quality, screened flexible data and control cable designed for low-frequency applications where electromagnetic interference (EMI) protection is essential. It features fine-stranded copper conductors, PVC insulation with DIN 47100 color-coded cores, and a tinned copper braid shield to reduce electrical noise and signal distortion.
The PVC outer sheath provides durability, flexibility, and easy handling in space-restricted installations. LiYCY cables are widely used in electronics, measurement and control systems, medical devices, computer equipment, and industrial automation, ensuring reliable signal transmission even in environments with electrical noise.
Key Features
Flexible PVC-insulated multi-core cable with tinned copper braid shield
Core identification according to DIN 47100
EMC protection against electrical noise and interference
Small outer diameter for tight installation spaces
Easy to strip and install
Flame retardant according to IEC 60332-1-2
RoHS-compliant
Technical Specifications
Conductor: Fine-stranded bare copper, Class 5 (IEC 60228)
Insulation: PVC, color-coded per DIN 47100
Screening: Tinned copper braid, optical coverage ≥ 85%
Sheath: PVC, grey (RAL 7001)
Core Count: 2 to 40 cores
Conductor Sizes: 0.14 mm², 0.25 mm², 0.34 mm², 0.5 mm², 0.75 mm², 1.0 mm²
Voltage Rating: 300 V / 500 V
Test Voltage: 1.5 kV
Temperature Range:
Fixed: −40 °C to +80 °C
Flexing: −5 °C to +70 °C
Bending Radius:
Fixed: ≥ 6× outer diameter
Flexing: ≥ 12× outer diameter
Standards: DIN VDE 0812, IEC 60228, IEC 60332-1-2
Typical Applications
Signal and control circuits with EMI protection needs
Data transmission in noisy environments
Measurement and instrumentation systems
Computer peripherals and office equipment
Light industrial automation and control
Audio and data control lines
5000m, 1000m, 100m upon request
